Microglass Elements



Microglass media cartridges are designed for maximum filtration performance in a wide range of oil, water and chemical fluid applications.  Our quality microglass elements replace the products of many manufacturers and OEMs while offering cost savings.

Reusable Bypass Vavle that replaces Hydac return line filters

Green Filter Technology

Hydraulic Elements, filters, micro fiberglass
Custom Hydraulic Filters, Microglass
Reusable Bypass Valve


Replace Hydacâ„¢ return line filter elements as well as filter elements from other manufacturers.



All return line elements utilize the latest generation of Bx(c)≥1000 (per ISO 16889) micro-fiberglass filter media. This media provides high levels of fluid cleanliness while maintaining low pressure drop characteristics.



Microglass Elements


Absolute rated elements for maximum performance, life and dirt holding capacity.

  • Pressure Side and Return Line Elements

  • Rated at a minimum Beta (Bx>) 200 efficiency

  • 1, 3, 6, 12 and 25 absolute micron ratings

  • Buna or Viton seals

  • Elements collapse ratings range between 150 PSID to 6,000 PSID

  • All micro-glass elements are potted and seam-sealed with epoxy-based adhesives

  • High collapse elements are double wire-backed for maximum support

  • High collapse elements have machined end caps for greater element integrity



Custom Microglass Elements


Designed to provide Bx(c)=1000 filtration efficiencies (ISO 16889) at 2.5, 5, 7, 12 and 22 microns with a minimum Bx=200 (ISO 4572) at 1, 3, 6, 12 and 25 micron ratings.  Designed to withstand from 150 PSID to 3250 PSID collapse pressure ratings.  For maximum element durability and long lifecycles, elements can be co-pleated with support layers, including

  • Polymer mesh

  • Annealed epoxy-coated steel wire

  • Stainless steel wire cloth
